Lichuan 220V 12NM 3 Phase Nema 34 Closed Loop Stepper Motor Driver With Digital Display

Name: Lichuan 220V 12NM 3 Phase Nema 34 Closed Loop Stepper Motor Driver With Digital Display
Brand: Lichuan
Price: 172.60 USD

Wholesale Lichuan 220V 12NM 3 Phase Nema 34 Closed Loop Stepper Motor Driver With Digital Display from china suppliers

Model Number : LCDA2260E+LC86H3156

Brand Name : Lichuan

Place of Origin : Guangdong, China

MOQ : 1 piece

Price : $172.60-188.30 / piece

Phase : 3

Type : Hybrid

Current / Phase : 3A

Warranty : 3 months ~ 1 year

Product name : 3 phase Nema 34 closed loop stepper motor driver

Motor Step/angle : 1.2

Motor Length : 156+22mm

Motor Holidng torque : 12N.m

Motor Motor weight : 5.5KG

Motor Rotor inertia : 3000 g.cm2

Driver voltage input : 150-230VAC

Driver Maximum current : 6A

Driver Subdivision range : 200 ~ 51200ppr

Driver Impulse response limit frequency : 200KHZ

Contact Now

Lichuan Motor Stepper AC 220V 12NM 3 Phase Nema 34 Closed Loop Stepper Motor Driver With Digital Display For CNC Router Kit

Packing List

NO.	Product Name	Model / Description	Quantity
1	Nema 34 closed loop stepper motor	LC86H3156	1
2	Nema 34 closed loop stepper driver	LCDA2260E	1
3	Driver encoder cable	Standard (3m)	1

Lichuan 220V 12NM 3 Phase Nema 34 Closed Loop Stepper Motor Driver With Digital Display

Products Description

3 phase 10NM NEMA34 Closed-loop stepper motor driver/ LC86H3156 information

LCDA2260E adopts the latest special motor control DSP chip and vector closed loop control technology, completely solves step missing issues for open loop stepper motor,obviously improves motor performance at high speed, reduces heat generation and vibration of motor, increases processing speed and precision of machine, decreases power consumption. When continuous overload of motor occurs, the Driver will timely output alarm signal, it is as reliable as AC servo system. Applies to motor installation dimensions which are fully compatible with Nema 34/42 series stepper motors, is convenient for upgrading traditional stepper driver solutions and largely reduces cost.

Lichuan 3 Phase Digital Hybrid Servo Driver
Product Model	LCDA2260E
Product Size	179.99139.967mm
Product Weight	1.22KG
Voltage input range	AC 150V~230V
Maximum output current	6A
Pulse form	Pulse + direction,CW/CCW
Logic input current	10~20mA
Pulse corresponding frequency	0~200kHz
insulation resistance	500MΩ

3 Phase Nema 34 Closed Loop Stepper Motor
Series	Step Angle(°)	Holding Torque(N.m)	Phase Current(A)	Length (mm)	Weight (kg)
LC86H398	1.2	6.0	3.0	123	3.5
LC86H3114	1.2	6.8	3.0	140	4.2
LC86H3129	1.2	10	3.0	154	4.7
LC86H3156	1.2	12	3.0	182	5.5
